Overall weight
6800KgMax mixing capacity
2.5m³Speed
30-35km/h1. Leading design, automatic feeding mixing system.
2. Easy to operate.
3. Efficient output,saving time, effort and cost.
4. Mixing tanker and loader, the transport truck is a perfect combination into the whole.
5. Rotated at 270 degrees mixing and discharge.
| Type | Integral frame chassis movable, self loading, transporting |
| Productivity | BATCH<15MINS, 4BATCHS/HOUR |
| Drive | 4 x4 |
| Steering | Rear wheels steering |
| Engine | YUNNEI ENGINE:FOUR-CYLINDER 2200RPM,76KW |
| Speed | HIGH SPEED : 32.5km/h; LOW SPEED : 5.5km/h |
| Gear Number | Four forwards, Four backwards |
| Tyre | 23.5-16 Steel wire tyre |
| Drum | Geometric volume 3.6 cubic meters, the beststirring 2.2-2.5cubic meter |
| Mixing drum | The tank rotates horizontally to 270degrees.There is no dead Angle for dischargingaround the vehicle |
| Shovel | 0.35m³ |
| Bucket discharge switch | Hydraulic gate, electric control |
| Operation Handle | Electric control button four-way pilot handle |
| Water Supply | Hydraulic driving self-primiing pumps |
| Water tank capacity | 370L |
| Diesel tank capacity | 180L |
| Whole weight | 6800KG COMPLETE VEHICLE MAX WEIGHT 6800kg |
