Overall weight
7450KgMax mixing capacity
3.0m³Speed
36.5km/h1. Leading design, automatic feeding mixing system.
2. Easy to operate.
3. Efficient output,saving time, effort and cost.
4. Mixing tanker and loader, the transport truck is a perfect combination into the whole.
5. Rotated at 270 degrees mixing and discharge.
| Type | Integral frame chassis movable, self loading, transporting |
| Productivity | BATCH<15MINS, 4BATCHS/HOUR |
| Drive | 4 x4 |
| Steering | Rear wheels steering |
| Engine | YUNNEI ENGINE:FOUR-CYLINDER 2200RPM,76KW |
| Speed | HIGH SPEED : 36.5km/h; LOW SPEED : 6.5km/h |
| Gear Number | Four forwards, Four backwards |
| Tyre | 16/70-20 |
| Drum | Geometric volume 6.8 cubic meters, the beststirring 2.6-3 cubic meters |
| Mixing drum | The tank rotates horizontally to 270degrees.There is no dead Angle for dischargingaround the vehicle |
| Shovel | 0.35m³ |
| Bucket discharge switch | Hydraulic gate, electric contro |
| Operation Handle | Electric control button four-way pilot handle |
| Water Supply | Hydraulic driving self-primiing pumps |
| Water tank capacity | 370L |
| Diesel tank capacity | 180L |
| Whole weight | 7450KG COMPLETE VEHICLE MAX WEIGHT 7450kg |
