Overall weight
8100KgMax mixing capacity
4.0m³Speed
36.5km/h1. Leading design, automatic feeding mixing system.
2. Easy to operate.
3. Efficient output,saving time, effort and cost.
4. Mixing tanker and loader, the transport truck is a perfect combination into the whole.
5. Rotated at 270 degrees mixing and discharge.
| Type | Integral frame chassis movable, self loading, transporting |
| Productivity | BATCH<15MINS, 4BATCHS/HOUR(14m³） |
| Drive | 4 x4 |
| Steering | Rear wheels steering |
| Engine | YUNNEI ENGINE:FOUR-CYLINDER 2200RPM,92KW |
| Speed | HIGH SPEED : 36.5km/h; LOW SPEED : 6.5km/h |
| Gear Number | Four forwards, Four backwards |
| Tyre | 16/70-20 |
| Drum | Geometric volume 5.0 cubic meters, the best stirring 3.5cubic meters |
| Mixing drum | The tank rotates horizontally to 270degrees.There is no dead Angle for dischargingaround the vehicle |
| Shovel | 0.55m³ |
| Bucket discharge switch | Hydraulic gate, electric contro |
| Operation Handle | Electric control button four-way pilot handle |
| Water Supply | Hydraulic driving self-primiing pumps |
| Water tank capacity | 520L |
| Diesel tank capacity | 180L |
| Whole weight | 8100KG COMPLETE VEHICLE MAX WEIGHT 8100kg |
